Product Specifications

Overview

SIMATIC IPC277E: The Panel PC with optimized performance – maintenance-free and compact with displays from 7"

The SIMATIC IPC277E Nanopanel PC is a flexible embedded industrial PC with rugged and durable displays.

Technologically it is based on the IPC227E Nanobox PC and thus offers maximum industrial functionality for flexible use even under harsh conditions – all without the need for maintenance.

The Panel PC is characterized by modern interfaces and a high degree of flexibility in the selection of the display. The latest Intel Dual-Core and Quad-Core processors ensure excellent performance here for visualization and control tasks.

Benefits

Offers great flexibility in the selection of rugged widescreen fronts

  • 7" – 19" widescreen displays with high resolution and wide viewing angles
  • Fully dimmable displays reduce energy consumption and increase service life

High degree of ruggedness for maintenance-free continuous operation

  • Maximum industrial functionality thanks to IP65 front and high electromagnetic compatibility
  • Backup of important system data thanks to non-volatile retentive memory (NVRAM, optional)
  • Designed for continuous operation at ambient temperatures up to 50 °C and high vibration/shock requirements
  • Maintenance-free operation – without fans (operation without battery possible)

Optimized for visualization tasks with additional functionality

  • High-performance and energy-saving dual-core and quad-core Intel Celeron processors
  • Diverse interfaces and configuration options (USB 3.0, 2 x Gbit Ethernet, RS 232/RS 485/RS 422, SSD/CFast)
  • Front USB for easy data exchange (15" / 19")

High investment security in order to reduce engineering costs

  • Long-term availability: Service & support period up to 11 years
  • Ideal platform for SIMATIC Software Controller and/or WinCC RT Advanced
  • Simple integration into automation solutions with the TIA Portal and on-board PROFINET interfaces

Application

The Nanobox PC has a diverse range of applications, including:

  • Visualization and control tasks, for example in mechanical engineering, plant construction, transportation systems or power transmission
  • Acquisition, further processing and visualization of data
  • Machine-level applications that additionally require C/C++ programs
  • Additionally, applications such as shipbuilding, building automation, and storage & logistics

Design

The SIMATIC IPC277E Nanopanel PC is a compact unit comprising an operator control unit with an integrated computing unit.

Computing unit:

  • Isolated power supply: 24 V DC (19.2 to 28.8 V)
  • Additional graphics connection display port:
    • Resolution: Up to 2 560 x 1 600 pixels
  • Interfaces (accessible from one side):
    • 2 x LAN 10/100/1 000 Mbps Ethernet interface (RJ45)
    • 1 x USB V3.0, 3 x USB V2.0 (7"/9": 2 x USB V2.0)
    • 1 x COM1 (RS 232 / RS 485 / RS 422, switchable in the BIOS)
  • Field bus
    • PROFINET Realtime via Standard Ethernet interface

Design versions

  • Processor / main memory configuration:
    • Intel Celeron N2807, 1.58 GHz, Dual Core
    • Intel Celeron N2930, 1.83 GHz, Quad Core
  • Main memory configuration:
    • 2 GB, 4 GB or 8 GB RAM
  • Retentive memory
    • 512 KB retentive memory (NVRAM), of which 128 KB can be written within the buffer time (optional)
  • Drives:
    • CFast drive (replaceable, accessible): 2 GB, 4 GB, 8 GB or 16 GB or
    • Solid-state drive 80 GB, 2.5" or
    • Solid-state drive 160 GB, 2.5"
  • Preinstalled operating systems:
    • Windows Embedded Standard 7 E / P
    • Windows 7 Ultimate, Multi-Language
    • 32-bit or 64-bit respectively

Components of the operator control unit:

The operator control units are available in the following versions:

7" Touch

  • 7" TFT color display, 800 x 480 pixels
  • Resistive analog touch screen

9" Touch

  • 9" TFT color display, 800 x 480 pixels
  • Resistive analog touch screen

12" Touch

  • 12" TFT color display, 1 280 x 800 pixels
  • Resistive analog touch screen

15" Touch

  • 15" TFT color display, 1 280 x 800 pixels
  • Resistive analog touchscreen with front USB interface

19" Touch

  • 19" TFT color display, 1 366 x 768 pixels
  • Resistive analog touchscreen with front USB interface

Integrated diagnostics DiagBase

  • Integrated, parameterizable monitoring functions (program execution / watchdog, internal enclosure temperature, mass storage)

Technical specifications

Order number

6AV7882-0...0-...0



SIMATIC IPC277E

Installation type/mounting



Design

Panel PC, built-in unit

maximum permissible installation angle +/-

45°

Supply voltage



Type of supply voltage

24 V DC

Mains buffering



  • ? Mains/voltage failure stored energy time

20 ms

Processor



Processor type

Intel Celeron N2807 / N2930

Drives



SSD

Yes; ≥ 80 GB optional

Memory



Type of memory

DDR3L

Main memory

2 / 4 / 8 GB

Data areas and their retentivity



retentive data area in total (incl. times, counters, flags), max.

512 kbyte; 128 KB can be stored in the buffer time; optional

Interfaces



USB port

1x USB 3.0 / 3x USB 2.0 (7"/9": 2x USB 2.0)

Connection for keyboard/mouse

USB / USB

serial interface

1x COM (1x RS 232 / 422 / 485), selectable in the BIOS

Video interfaces



  • ? Graphics interface

1x DisplayPort

Industrial Ethernet



  • ? Industrial Ethernet interface

Onboard, 2x 10 / 100 / 1000 Mbit, RJ45

  • — 100 Mbps

Yes

  • — 1000 Mbps

Yes

Monitoring functions



Temperature

Yes

Watchdog

Yes

Status LEDs

No

Fan

No

Monitoring function via network

Optional

EMC



Interference immunity against discharge of static electricity



  • ? Interference immunity against discharge of static electricity

±6 kV contact discharge acc. to IEC 61000-4-2; ±8 kV air discharge acc. to IEC 61000-4-2

Interference immunity against high-frequency electromagnetic fields



  • ? Interference immunity against high frequency radiation

10 V/m, 80 MHz to 2 GHz, 80 % AM acc. to IEC 61000-4-3; 3 V/m, 2 GHz to 2.7 GHz, 80 % AM acc. to IEC 61000-4-3; 10 V, 10 kHz to 80 MHz, 80 % AM acc. to IEC 61000-4-6

Interference immunity to cable-borne interference



  • ? Interference immunity on supply cables

±2 kV acc. to IEC 61000-4-4, burst; ±1 kV acc. to IEC 61000-4-5, surge symmetric; ±2 kV acc. to IEC 61000-4-5, surge asymmetric

  • ? Interference immunity on signal cables >30m

±2 kV acc. to IEC 61000-4-5, surge, length > 30 m

  • ? Interference immunity on signal cables < 30m

±1 kV acc. to IEC 61000-4-4; burst; length < 3 m; ±2 kV acc. to IEC 61000-4-4; burst; length > 3 m

Interference immunity against voltage surge



  • ? asymmetric interference

±2 kV acc. to IEC 61000-4-5, surge asymmetric

  • ? symmetric interference

±1 kV acc. to IEC 61000-4-5, surge symmetric

Interference immunity to magnetic fields



  • ? Interference immunity to magnetic fields at 50 Hz

100 A/m; to IEC 61000-4-8

Emission of conducted and non-conducted interference



  • ? Interference emission via line/AC current cables

Noise emission: EN 61000-6-4:2007 +A1:2011 (industrial environments), CISPR 22 Class B, FCC Class A

Degree and class of protection



IP (at the front)

IP65

IP (rear)

IP20

Standards, approvals, certificates



CE mark

Yes

UL approval

Yes

  • ? UL 508

Yes

cULus

Yes

RCM (formerly C-TICK)

Yes

KC approval

Yes

FCC

Yes

EMC

CE, EN 61000-6-4:2007 +A1:2011, EN 61000-6-2:2005

  • ? EN 61000-6-2

Yes

Marine approval



  • ? Germanischer Lloyd (GL)

Yes; 7", 9", 12"

  • ? American Bureau of Shipping (ABS)

Yes; 7", 9", 12"

  • ? Bureau Veritas (BV)

Yes; 7", 9", 12"

Ambient conditions



Ambient temperature during operation



  • ? Ambient temperature during operation

0 °C to 50 °C

  • ? min.

0 °C

  • ? max.

50 °C; 19": max. 45 °C

Relative humidity



  • ? Relative humidity

Tested according to IEC 60068-2-78, IEC 60068-2-30: Operation: 5 % to 85 % at 30 °C (no condensation), storage / transport: 5 % to 95 % at 25 / 55 °C (no condensation)

Vibrations



  • ? Vibration load in operation

Tested according to IEC 60068-2-6: 5 Hz to 8.4 Hz: 3.5 mm, 8.4 Hz to 500 Hz: 9.8 m/s²

Shock testing



  • ? Shock load during operation

Tested according to IEC 60068-2-27: 50 m/s², 30 ms

Operating systems



Operating system

Windows 7 Ultimate 32-bit / 64-bit, MUI; Windows Embedded Standard 7 E/P, 32-bit / 64-bit

pre-installed operating system

Yes

without operating system

Yes

pre-installed operating system



  • ? Windows 7

Yes; Ultimate 32 bits or 64 bits

Software



SIMATIC Software

Optional package with SIMATIC WinCC or WinAC RTX



Order number

6AV7882-0A..0-...0

6AV7882-0B..0-...0

6AV7882-0C..0-...0

6AV7882-0D..0-...0

6AV7882-0E..0-...0



SIMATIC IPC277E, 7" TOUCH

SIMATIC IPC277E, 9" TOUCH

SIMATIC IPC277E, 12" TOUCH

SIMATIC IPC277E, 15" TOUCH

SIMATIC IPC277E, 19" TOUCH

General information











Product type designation

7" Touch

9" Touch

12" Touch

15" Touch

19" Touch

Display











Design of display

7" TFT Touch

9" TFT Touch

12" TFT Touch

15" TFT Touch

19" TFT Touch

Screen diagonal

7 in

9 in

12 in

15 in

19 in

Resolution (pixels)











  • ? Resolution (WxH in pixel)

800 x 480

800 x 480

1280 x 800

1280 x 800

1366 x 768

Backlighting











  • ? MTBF backlighting (at 25 °C)

80 000 h

80 000 h

80 000 h

80 000 h

50 000 h

Control elements











Input device











  • ? Mouse, at front







Front USB 2.0 (500mA)

Front USB 2.0 (500mA)

Installation type/mounting











central design

Yes

Yes

Yes

Yes

Yes

Mounting in portrait format possible

Yes

Yes

Yes

Yes

Yes

Power loss











In full configuration

26 W

33 W

33 W

36 W

36 W

Dimensions











Width of the housing front

214 mm

274 mm

330 mm

415 mm

483 mm

Height of housing front

158 mm

190 mm

241 mm

310 mm

337 mm

Mounting cutout/device depth (W x H x T)

197 mm x 141 mm x 77 mm

251 mm x 166 mm x 77 mm

310 mm x 221 mm x 73 mm

395 mm x 290 mm x 73 mm

464 mm x 318 mm x 73 mm

Weights











Panel PC in central design, approx.

1.5 kg

1.95 kg

2.75 kg

4 kg

5.7 kg
